With its Multi Step design, VRF BSR Series Y-Joints can be used with any VRF system. BSR Series Ref Joint comes with UV Stabilized Fire Grade XPLE Insulation which prevents Sweating of Ref Joints.
| Model No | Pipe A (ID) | Pipe-B (ID) | Pipe-C (ID) |
|---|---|---|---|
| Pi-BVRJ-5-6-I (Gas Side) | 12.07 - 15.88 - 19.05 | 19.05 - 15.88 - 12.7 | 19.05 - 15.88 - 12.7 |
| Pi-BVRJ-5-6-I (Liquid Side) | 6.35 - 9.52 - 12.7 | 12.7 - 9.52 - 6.35 | 12.7 - 9.52 - 6.35 |
| Pi-BVRJ-8-19-I (Gas Side) | 19.05 - 22.22 - 28.58 - 31.75 | 31.75 - 28.58 - 22.22 - 19.05 - 15.88 - 12.7 | 31.75 - 28.58 - 22.22 - 19.05 - 15.88 - 12.7 |
| Pi-BVRJ-8-19-I (Liquid Side) | 9.52 - 12.7 - 15.88 | 15.88 - 12.7 - 9.52 - 6.35 | 15.88 - 12.7 - 9.52 - 6.35 |
| Pi-BVRJ-24-63-I (Gas Side) | 41.28 - 34.93 | 34.93 - 28.58 - 22.22 - 19.05 - 15.88 - 12.7 | 34.93 - 41.28 |
| Pi-BVRJ-24-63-I (Liquid Side) | 12.7 - 15.88 - 19.05 - 22.22 | 19.05 - 15.88 - 12.7 - 9.52 | 22.22 - 19.05 - 15.88 - 12.7 |
| Pi-BVRJ-24-63-O (Gas Side) | 28.58 - 34.93 - 41.28 | 34.93 - 28.58 | 41.28 - 34.93 - 28.58 |
| Pi-BVRJ-24-63-O (Liquid Side) | 15.88 - 19.05 | 19.05 - 15.88 - 12.7 | 19.05 - 15.88 |
