TA Series

REF Joint for all types of VRF Systems working on R410 Refrigerant

product-specification-banner-image

TA Series Branch Piping Kit was created specifically to work with variable refrigerant flow systems and is capable of withstanding the greater pressures that these systems produce.

VRF TA Series Joint uses a variety of separation tubes, headers, and appropriate connectors. Every Joint which we manufacture goes through stringent quality control, each Y-Joint has to pass 5.2MPa pressure test before packing. Optimized shape dimension of our Ref Joints ensures enhanced fluency of refrigerant thereby increase overall cost performance of the VRF System.

TA Series

ta series image

TA Series

ta series image

TA Series

ta series image

Features of TA Series

Product Specifications

Pipe-A Pipe-B Pipe-C Reducer Sets
Pi-RBM-55E (Gas Side) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 2, 3×2, 15×2
Pi-RBM-55E (Liquid Side) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 1×2
Pi-RBM-105E (Gas Side) 22.22 (7/8) 22.22 (7/8) 22.22 (7/8) 15, 4×2, 5×2
Pi-RBM-105E (Liquid Side) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 2, 15, 16
Pi-RBM-205E (Gas Side) 21.75 (11/4) 28.58 (11/8) 28.58 (11/8) 6, 7×2, 8, 9, 10, 15
Pi-RBM-205E (Liquid Side) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 2, 3×2, 16
Pi-RBM-305E (Gas Side) 81.10 (11/2) 81.10 (11/2) 81.10 (11/2) 7, 11, 12×2, 13×3, 14×2, 15
Pi-RBM-305E (Liquid Side) 22.22 (7/8) 22.22 (7/8) 22.22 (7/8) 15, 16, 17×2

Reducer No. & Size

1 OD 9.52 (3/8) – 6.35 (1/4)
2 OD 15.88 (5/8) x 12.7(1/2)
3 OD 15.88 (5/8) x 19.05 (3/4)
4 OD 22.22 (7/8) x 15.88 (5/8)
5 OD 22.22 (7/8) x 28.58 (11/8)
6 OD 28.58 (11/8) x 15.88 (5/8)
7 OD 28.58 (11/8) x 22.2 (7/8)
8 OD 28.58 (11/8) x 34.93 (13/8)
9 OD 31.75 (11/4) x 28.58 (11/8)
10 OD 31.75 (11/4) x 34.93 (13/8)
11 OD 38.1 (11/2) x 15.88 (5/8)
12 OD 38.1 (11/2) x 28.58 (11/8)
13 OD 38.1 (11/2) x 34.93 (13/8)
14 OD 38.1 (11/2) x 41.28 (15/8)
15 OD 15.88 (5/8) x 12.7 (1/2) x 9.52 (3/8)
16 OD 15.88 (5/8) x 12.7 (1/2) x 9.52 (3/8) x 6.35 (1/4)
17 OD 222 (7/8) x 19.05 (3/4) x15.88 (5/8)
